Specs
- Input Voltage: 10-30V DC
- Wattage: 36W (12-3W LEDs)
- Raw Lumens: 2880
- Color Temperature: 6000K
- Beam Pattern: combo – flood (90°)/spot (8°)
Construction
- Die-cast Aluminum Housing
- Housing Color: White Coating with UV Inhibitors
- Membrane: Gore™
- Lens Material: PC
- Mounting Bracket: Die-cast Aluminum
- Hole Dimensions: Brackets turned inward – 7.25"
- Brackets turned outward – 9.5"
- Mounting Bolt Drill – .25"
- Electronics: Integrated-Epoxy Encapsulated
- Hardware: Stainless 316
Operation
- Operating Temperature: -40°C to +60°C
- Current Consumption: 1.9 amps at 13.8 volts
- IP Rating: IP68
- Protections: Reverse Polarity
